Category

Specification

DISPLAY

Panel Type

Transmissive TFT, 262K color

Diagonal

1.54 in / 39.1 mm

Resolution

240 x 240 px

Refresh Rate

30 Hz

Brightness

300 cd/m²

Colors

18-bit

Orientation

Software adjustable

PUMP

Name

NZXT Turbine

Motor Speed

1,200 – 2,800 ± 300 RPM

Power

12 V DC, 0.3 A

CAP

Diameter

2.87 in / 72.95 mm

Height

2.2 in / 55.97 mm

Housing Material

Plastic

COLD PLATE

Dimensions

56 mm x 56 mm

Type

Split flow

Material

Copper

RADIATOR

Dimensions

281 x 120 x 27 mm

Material

Aluminum

TUBING

Length

400 mm

Material

CIIR rubber with Nylon braided sleeve

FAN SPECS

Model

F120P Static Pressure Fan

Color

Black

Dimensions

120 x 120 x 25 mm

Quantity

2

Speed

500 - 2,000 ± 200 RPM

Airflow

73.47 CFM

Static Pressure

4.50 mm-H₂O

Noise Level

30.0 dBA

Power Consumption

12V DC, 0.18 A, 2.16 W

Connector

4-pin PWM

Bearing

Fluid Dynamic Bearing

Lifespan

60,000 hours

LED Quantity

N/A

Cable Length

600 mm

Materials

Plastic, rubber, PCB

SOCKET SUPPORT

Intel®

LGA 1851/1700, 1200/115X

AMD®

AM5, AM4

CPU SUPPORT

Intel®

Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron

AMD®

AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3

PRODUCT INFO

Warranty

6 Years
